Switchable MM/MC Phono Stage
--
Housed within our latest half width custom designed case are two entirely separate, high performance phono stages. One fully adjustable, dedicated moving coil and one moving magnet. Each stage is designed and engineered to maximize the potential of your vinyl system whilst remaining easy to use and set up.
Maximum output level = 11v RMS
Rated output level = 200mV
Output resistance = 100U
Minimum output resistance for a –3dB point at 15Hz = 1K
AC supply 230v & 115v Nominal +/- 10%
230v 20mm Fuse T250mAL
115v 20mm Fuse T500mAL
Power Consumption = 10 Watts
Ambient operating temperature 5 to 35°C
Dimensions: W 220mm x D 320mm x H 80mm
