A 130 mm driver in a narrow opening
CWM652 packs a Nautilus tweeter and HF adjustment into a 228 × 153 mm cut-out.
The Bowers & Wilkins CWM652 pair needs two rectangular 228 × 153 mm openings. Each frame is 264 × 191 mm, with 95 mm of clear depth behind the wall and 4 mm front protrusion. This is the narrowest Performance CWM format here, useful where stud spacing limits the width of the cut.
Key features
- Cut-out 228 × 153 mm; frame 264 × 191 mm; depth 95 mm.
- 130 mm Kevlar bass/midrange and 25 mm Nautilus aluminium tweeter.
- 8-ohm impedance (4.5-ohm minimum); 25–100 W specified power.
- Three-position HF switch; QuickDogs; PMK W5.
Treble adjustment
The 130 mm Kevlar bass/midrange driver has a die-cast chassis, while a 25 mm aluminium-dome tweeter uses Nautilus tube loading. A three-position switch refines high-frequency output. CWM663 steps up to a 150 mm driver and larger cut-out; CWM652 retains a more compact footprint for distributed rooms or several channels.
Electrical and fitting figures
Sensitivity is 86 dB and nominal impedance 8 ohms with a 4.5-ohm minimum. Amplifier power is specified at 25 to 100 W and the -6 dB range is 54 Hz to 50 kHz. QuickDogs and a convenient connection help fitting. PMK W5 is the pre-mount kit and BB 6W the listed back box; allow room for these and access to the terminals before finishing the wall.
The 153 mm cut-out width helps where usable wall space is limited, but the full 191 mm frame must clear features on the room side. The HF control provides a way to refine the result near furnishings or reflective surfaces without recutting the wall. Evaluate the setting with the pair installed in the finished room, and keep enough access for final adjustments. The 95 mm cavity depth must remain unobstructed behind each opening.
