3-way electrostatic/hybrid center channel, air suspension, dual 133mm aluminum cone woofers, 584x162mm CLS XStat™ controlled dispersion curvilinear electrostatic ribbon midrange, 26x36mm Folded Motiont ribbon tweeter. Power 20-300W. Efficiency 89dB. Impedance 4 ohms.
SPECIFICATIONS:
-
Frequency Response: 66-23,000Hz ±3dB
-
Recommended amplifier power: 20-300 watts per channel
-
Horizontal dispersion: 30°
-
Vertical dispersion: 16cm line source
-
Sensitivity: 89dB / 2.83 volts / meter
-
Impedance: 4 Ohms Compatible with amplifiers with 4, 6 or 8 Ohms
-
Crossover Frequency: 600, 3400Hz
-
High Frequency Transducer: One folded 2.6x3.6 cm transducer with 13.3x4.4 cM diaphragm
|
-
Medium Frequency Transducer: XStat ™ CLS ™ electrostatic transducer. Panel size: 16.1x58.4cm. Radiant area: 940 cm²
-
Low Frequency Driver: Two 13.3 cm high-excursion high-rigidity aluminum cone with extended launch driver assembly, non-resonant asymmetric chamber format
-
Components: Custom wound audio transformer, air core coils, low DCR steel laminated coils, polyester capacitors
-
Inputs: Custom 5-way toolless binding posts
-
Weight: 14.5kg
-
Dimensions: 19.3x57.9x40.9cm
|
