Stainless steel wall bracket with two articulated arms for outdoor TVs
IP-DA is a manual double-arm wall bracket: the screen can be drawn out from the wall and turned to either side, through an angle that depends on how wide the television is.
Future Automation builds it to order from stainless steel, which protects it against corrosion when it is installed in the open air. It is offered in four standard sizes, or with arms cut to a chosen length for sites where a stock bracket does not fit.
Key features
- Manual movement: the screen pulls out from the wall and swings left or right
- Solid stainless steel structure that keeps the display firmly held
- Corrosion protection for use outside
- Four standard sizes: IP-DA1, IP-DA2, IP-DA3 and IP-DA4
- Arms cut to measure, each as long as 500 mm
- Suitable for indoor and outdoor use
Available sizes
IP-DA1 extends as far as 800 mm and takes VESA patterns as large as 200 x 200. IP-DA2 and IP-DA3 share the 800 mm maximum extension, accept VESA patterns as large as 400 x 400 and are suggested for 40" to 75" and 55" to 75" screens respectively. IP-DA4 reaches 1000 mm of extension, again with VESA patterns as large as 400 x 400, and is suggested for screens from 65" to 75".
Custom lengths
Beyond the four standard sizes, the bracket can be made in bespoke lengths of as much as 1 metre. The Future Automation design team adjusts how long each arm is, so that the result meets the requirements of the installation.
