MoFi MasterTracker MM: moving-magnet cartridge with Micro-Line stylus
The MasterTracker MM is a stereo moving-magnet cartridge from MoFi Electronics. Like the other cartridges of the brand, it takes as its model the cutting lathe used by Mobile Fidelity Sound Lab: the V-Twin generator employs two strong magnets of low mass, set in a V shape and parallel to the grooves as in the cutting head. Among the models of the Tracker series it is the one with the lightest magnets.
The stylus is a Micro-Line diamond, with a profile similar to that of the tip that cuts the record, and it follows the groove walls with great precision; it is fitted to a tapered aluminium cantilever. The body, machined from an aluminium billet and well damped, controls resonances to the benefit of tight, precise bass. The coils are made of Ohno continuous-cast copper. The stated load is 47 kOhm.
Technical features
- Type: stereo dual-magnet (MM), V-Twin generator
- Stylus: Micro-Line
- Cantilever: tapered aluminium
- Coils: Ohno continuous-cast copper
- Output voltage: 3 mV
- Frequency response: from 20 to 25,000 Hz
- Tracking force: from 1.8 to 2.2 g
- Load impedance: 47 kOhm, with 100 pF capacitance
- Weight: 9.7 g
Available versions
Sold as a single unit.
